Intelligent Barcode & OCR package
By delivering full support for most common barcodes with built-in check digits and start/stop characters automatic insertion, the Intelligent Barcode & OCR Package optimises the return on investment in your multifunctional products and laser printers. This intelligent barcode solution enables the full use of the built-in printing capabilities of Ricoh MFPs and laser printers such as paper tray selection, double-sided printing, stapling and hole punching. As this Intelligent Barcode & OCR software installed inside your MFPs also support the industry standard 2D barcode PDF417, it allows you to improve your workflow, save valuable time and maximise efficiency.
This software based barcode solution is available in two modes, offering you the opportunity to try the package before buying a license for each supported model. With the included software tool 'Config Tool', you can install and manage all licensed MFPs and laser printers remotely, from one central workstation. In short: this package guarantees the most complete barcode and OCR solution available.
- Specifications
-
Barcode
Printer language
PCL5/PCL5c/PCL5eBarcode types
- Code 128 A/B/C, code 128 auto-switch UCC/EAN-128, UPC-128/SSCC-18, UPS-128
- Code 39 (+CHK), code 39 extended (+CHK) Danish PTT 39, French postal 39 A/R, PZN (Pharma-Zentral-Nummer)
- Code 93, code 93 extended
- Codabar, AIM Codabar
- 2 of 5 interleaved (+CHK) German postal (Deutsche Post AG) Leit-/Identcode (13/11 digits), USPS 25 tray/sack label (10/8 digits)
- 2 of 5 industrial (+CHK)
- 2 of 5 matrix (+CHK)
- Code 11 (+CHK 11 or 11/11)
- MSI Plessey (+CHK 10 or 10/10 or 11/10)
- USPS POSTNET (5/9/11 digits), FIM, ZEBRA
- EAN/JAN-13 (+2/5-digit add-on), EAN/JAN-8 (+2/5-digit add-on), EAN/JAN Velocity
- UPC-A (+2/5-digit add-on), UPC-E (+2/5-digit add-on)
- Australian 4-state postal, KIX, RM4SCC, Singapore 4-state
- (2D) PDF417
Font size control
Scalable length and widthOCR Font
Printer language
PCL5/PCL5c/PCL5eFont type
- PCL fonts
- OCR fonts
- OCR-A, OCR-A1
- OCR-B
Font size control
Scalable length and widthBarcode & OCR Package Config Tool
Required environment
Hardware
IBM/compatible PC/laptop (minimum Pentium II 300 MHz, 128 MB RAM)Software
- Windows® 2000 SP4/XP SP2/NT4.0 SP6
- Internet Explorer® 5.0 or higher
Intelligent Barcode & OCR package installation support
- Automatic device discovery
- Firmware, system & NIB version check
- BOCR program installation
Device discovery
Automatic device discovery in network (TCP/IP)Functionality differs per model used. For availability of models, specific functionality, optional apparatus, system requirements and software, please consult your local Ricoh supplier.
All brand and/or product names are trademarks of their respective owners. Specifications are subject to change without prior notice.
